DOMADIA™ Beryllium Copper UNS C17510 – The Alloy That Bench-Presses Steel and Outsmarts Copper
Why settle for average when your material can do both the heavy lifting and high-voltage thinking?
DOMADIA™ Beryllium Copper UNS C17510 (CuNi2Be) is your go-to alloy when strength, smarts, and conductivity are non-negotiable. It performs like a bodybuilder with an engineering degree—strong, reliable, and precision-tuned.
Whether you’re designing aerospace components or high-end electrical connectors, our rods and bars don’t just meet specs—they show off.
Chemical Composition (UNS C17510 / CuNi2Be)
| Element | Content (%) |
| Copper (Cu) | Balance |
| Beryllium (Be) | 0.2 – 0.6 |
| Nickel (Ni) | 1.4 – 2.2 |
| Cobalt (Co) | ≤ 0.35 |
| Others | ≤ 0.2 |
This unique blend gives C17510 its exceptional thermal conductivity, corrosion resistance, and mechanical strength.
Applications: Trusted Across Critical Industries
Beryllium Copper UNS C17510 is the engineer’s secret weapon, especially in:
- Electrical/Electronics: Connectors, contacts for switches and relays, relay blades, conductors, switchgear components.
- Fasteners: Washers, lock washers, retaining rings, roll pins, screws, bolts.
- Industrial: High flux electromagnets, thermal transfer plates, welding equipment, springs, die casting plunger tips.
- Welding: Welding electrodes, electrode tips, and sealing moulds.
- Molds: Plastic molds, particularly for high-stress applications.
- Other: Bearings, springs, precision screw machined parts, corrosion-resistant components, and current-carrying springs.
Properties & Technical Specs
| Property | Value |
| Density | ~8.36 g/cm³ |
| Electrical Conductivity | 45 – 60 % IACS |
| Hardness (HB) | Up to 300 (after aging) |
| Yield Strength | Up to 700 MPa |
| Tensile Strength | 1000+ MPa (peak-aged) |
| Elastic Modulus | ~131 GPa |
| Operating Temperature | -200°C to 300°C |
These figures ensure high load-bearing capacity, even under thermal cycling and corrosive environments.
Other Designations
Equivalent materials to UNS C17510 beryllium copper alloys are:
- ASTM B441
- ASTM B534
- MIL C-81021
- SAE J461
- SAE J463
Available Shapes
We supply DOMADIA™ C17510 in the following forms:
(Customized sizes and tempers available upon request.)
Conclusion: The Alloy That Knows No Compromise
If you’re seeking an alloy that delivers both brains and brawn, look no further than DOMADIA™ Beryllium Copper UNS C17510. Whether it’s about withstanding pressure, conducting performance, or resisting wear, this CuNi2Be alloy stands tall.
Choose DOMADIA™. Choose precision engineered reliability.
